High-efficiency EA-ELR 10000 2U series programmable regenerative DC electronic loads with wide 80–1500V voltage, 6–120A current, and 1500–3000W power in a 2U 19‑inch rack enclosure. Featuring up to 95% energy recovery, a 5″ TFT touch panel, built-in arbitrary function generator, master‑slave parallel capability for up to 64 units, and galvanically isolated analog/USB/Ethernet interfaces with optional CAN, Profibus, ProfiNet, EtherCAT, and more, they are expertly suited for battery testing, solar panel MPPT simulation, automotive electronics, and high‑power industrial test systems demanding energy efficiency and precision.

Model

ELR 10080-60 2U, ELR 10200-25 2U, ELR 10360-15 2U, ELR 10500-10 2U, ELR 10750-06 2U, ELR 10080-120 2U, ELR 10200-50 2U, ELR 10360-30 2U, ELR 10500-20 2U, ELR 10750-12 2U, ELR 11000-10 2U, ELR 11500-06 2U

DC Input Power (Max/Derated)

1500W / 1200W, 3000W / 1500W

DC Input Voltage (CV Range)

0-80V, 0-200V, 0-360V, 0-500V, 0-750V, 0-1000V, 0-1500V

DC Input Current (CC Range)

0-6A, 0-10A, 0-12A, 0-15A, 0-20A, 0-25A, 0-30A, 0-50A, 0-60A, 0-120A AC Input (Active PFC): 110-240V AC

Type

Programmable Regenerative DC Electronic Load

External Control

Analog, USB, Ethernet, Optional CAN, Optional CANopen, Optional RS232, Optional Profibus, Optional ProfiNet, Optional ModBus TCP, Optional EtherCAT

Housing

19" 2U Rackmount

Special Features

Energy Recovery up to 95%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, Discharge Circuit (≥200V models), SCPI, ModBus RTU, LabView VIs

GET A QUOTE

Add to Quote List View Quote List

Description

Model Overview – All Values

Model	DC Input Power (Max/Derated)	DC Input Voltage (CV Range)	DC Input Current (CC Range)	AC Input (Active PFC)	Type	External Control	Housing	Special Features
ELR 10080-60 2U	1500W / 1200W	0-80V	0-60A	110-240V AC	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 2U Rackmount	Energy Recovery up to 94%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, SCPI & ModBus RTU, LabView VIs
ELR 10200-25 2U	1500W / 1200W	0-200V	0-25A	110-240V AC	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 2U Rackmount	Energy Recovery up to 94.5%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, Discharge Circuit, SCPI & ModBus RTU, LabView VIs
ELR 10360-15 2U	1500W / 1200W	0-360V	0-15A	110-240V AC	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 2U Rackmount	Energy Recovery up to 94.5%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, Discharge Circuit, SCPI & ModBus RTU, LabView VIs
ELR 10500-10 2U	1500W / 1200W	0-500V	0-10A	110-240V AC	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 2U Rackmount	Energy Recovery up to 95%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, Discharge Circuit, SCPI & ModBus RTU, LabView VIs
ELR 10750-06 2U	1500W / 1200W	0-750V	0-6A	110-240V AC	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 2U Rackmount	Energy Recovery up to 95%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, Discharge Circuit, SCPI & ModBus RTU, LabView VIs
ELR 10080-120 2U	3000W / 1500W	0-80V	0-120A	110-240V AC	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 2U Rackmount	Energy Recovery up to 94%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, SCPI & ModBus RTU, LabView VIs
ELR 10200-50 2U	3000W / 1500W	0-200V	0-50A	110-240V AC	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 2U Rackmount	Energy Recovery up to 94.5%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, Discharge Circuit, SCPI & ModBus RTU, LabView VIs
ELR 10360-30 2U	3000W / 1500W	0-360V	0-30A	110-240V AC	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 2U Rackmount	Energy Recovery up to 94.5%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, Discharge Circuit, SCPI & ModBus RTU, LabView VIs
ELR 10500-20 2U	3000W / 1500W	0-500V	0-20A	110-240V AC	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 2U Rackmount	Energy Recovery up to 95%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, Discharge Circuit, SCPI & ModBus RTU, LabView VIs
ELR 10750-12 2U	3000W / 1500W	0-750V	0-12A	110-240V AC	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 2U Rackmount	Energy Recovery up to 95%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, Discharge Circuit, SCPI & ModBus RTU, LabView VIs
ELR 11000-10 2U	3000W / 1500W	0-1000V	0-10A	110-240V AC	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 2U Rackmount	Energy Recovery up to 95%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, Discharge Circuit, SCPI & ModBus RTU, LabView VIs
ELR 11500-06 2U	3000W / 1500W	0-1500V	0-6A	110-240V AC	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 2U Rackmount	Energy Recovery up to 95%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, Discharge Circuit, SCPI & ModBus RTU, LabView VIs

30-Second Fit Check

Need an energy-saving DC load for high-power testing? Models cover 0-80V to 0-1500V, with currents up to 120A.
Output power: 1500W or 3000W with regenerative energy recovery up to 95% back to the grid.
Four regulation modes: Constant Voltage (CV), Constant Current (CC), Constant Power (CP), Constant Resistance (CR).
Built-in 5" TFT touch panel with two rotary knobs; supports master-slave parallel operation for up to 64 units (192kW).
Comprehensive protection: OVP, OCP, OPP, OT, PF, MSP, SF; Share bus for dynamic current balancing in parallel systems.

What It Is + Why It Matters

Regenerative electronic DC loads in 2U 19" rack format that feed consumed DC energy back to the local grid with up to 95% efficiency – drastically reducing cooling costs and energy waste.
An integrated function generator (sine, triangle, square, trapezoid, ramp, DIN 40839, arbitrary, XY table) plus dedicated battery test and MPPT tracking modes for comprehensive component testing.
True master-slave parallel operation with summed actual values and shared setpoints across units, plus a Share bus for dynamic voltage balancing – scalable to 192kW.
Flexible connectivity: built-in analog (0-5/10V), USB, Ethernet, plus optional plug-in modules for CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT.

Note: These are energy-recovering devices that feed power back into the local grid. Consult local utility regulations and consider a grid protection device. Must be installed in a closed 19" rack with proper ventilation.

Key Specs

AC input: 1500W: 110-240V AC, 3000W: 110-240V AC, single phase, active PFC, 45-65Hz.
DC input voltage: 0-80V up to 0-1500V; Current: 0-6A up to 0-120A.
DC input power: 0-1500W or 0-3000W (derating to 1200W/1500W at 110-127V AC input).
Energy recovery efficiency: up to 95% at full power; regulation accuracy: CV ≤0.05%, CC ≤0.1%.
Display: 5" TFT colour touchscreen (800x480), 2 rotary knobs with push function, panel lock.
Interfaces: 15-pin analog (0-5/10V), USB-B, USB-A, Ethernet, plus optional industrial bus modules.
Master-slave bus (RS485 via RJ45) + Share bus (BNC) for up to 64 units parallel operation.
Dimensions (WxHxD): 19" x 2U x approx. 500mm; Weight: approx. 12.5-13.5 kg (model dependent).

Integration & Installation

DC input on rear panel with copper blade terminals; includes plastic covers for contact protection and strain relief accessories.
AC mains via 3-pole clamp terminal (L, N, PE); requires rigid connection in a closed 19" cabinet; external circuit breaker recommended.
Master-slave connection via standard CAT5 patch cables; Share bus via BNC coaxial cables (50Ω); supports mixed power classes within the same series.
Optional interface modules are user-installable in the rear slot; ESD precautions apply during module exchange.
Must be installed in a closed 19" rack/cabinet with lockable doors; ensure adequate ventilation and consult grid regulations for energy feedback.

Best for / Not for

Best for: High-power battery discharge testing, solar panel MPP profiling, automotive 12V/24V/48V/400V system validation, power supply burn-in testing, and large-scale industrial test systems requiring energy efficiency and scalable parallel operation.
Not for: AC load applications, series connection of DC inputs (not permitted), operation without proper energy recovery grid compliance, or environments without adequate rack cooling.

Selection Checklist + RFQ

Choose voltage/current model matching your source specifications (80V to 1500V, 6A to 120A).
Confirm total power requirement ≤ 1500W or 3000W; note derating to 1200W/1500W at 110-127V AC input.
Verify AC supply voltage (110-240V AC single phase) and plan for proper grid compliance regarding energy recovery.
Select required interfaces: built-in analog/USB/Ethernet plus any optional industrial bus modules (CAN, Profibus, ProfiNet, EtherCAT, etc.).
For master-slave operation, specify total system power and number of units; ensure all units have same voltage rating.
Plan for installation in a closed 19" rack with adequate cooling and lockable doors.
