High-efficiency EA-ELR 10000 3U series programmable regenerative DC electronic loads with wide 80–2000V voltage, 20–510A current, and 5–15kW power in a 3U 19‑inch rack enclosure. Featuring up to 95.5% energy recovery, a 5″ TFT touch panel, built-in arbitrary function generator, master‑slave parallel capability for up to 64 units (960kW), and galvanically isolated analog/USB/Ethernet interfaces with optional CAN, Profibus, ProfiNet, EtherCAT, and more, they are expertly suited for battery testing, solar panel MPPT simulation, automotive electronics, and high‑power industrial test systems demanding energy efficiency and precision.

Model

ELR 10080-170, ELR 10200-70, ELR 10360-40, ELR 10500-30, ELR 10750-20, ELR 10080-340, ELR 10200-140, ELR 10360-80, ELR 10500-60, ELR 10750-40, ELR 11000-30, ELR 11500-20, ELR 10080-510, ELR 10200-210, ELR 10360-120, ELR 10500-90, ELR 10750-60, ELR 11000-40, ELR 11500-30, ELR 12000-20

DC Input Power (Max/Derated)

5000W / 3000W, 10000W / 6000W, 15000W / 9000W

DC Input Voltage (CV Range)

0-80V, 0-200V, 0-360V, 0-500V, 0-750V, 0-1000V, 0-1500V, 0-2000V

DC Input Current (CC Range)

0-20A, 0-30A, 0-40A, 0-60A, 0-70A, 0-80A, 0-90A, 0-120A, 0-140A, 0-170A, 0-210A, 0-340A, 0-510A

AC Input

208-480V AC, 3ph (active PFC)

Type

Programmable Regenerative DC Electronic Load

External Control

Analog, USB, Ethernet, Optional CAN, Optional CANopen, Optional RS232, Optional Profibus, Optional ProfiNet, Optional ModBus TCP, Optional EtherCAT

Housing

19" 3U Rackmount

Special Features

Energy Recovery up to 95.5%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, SCPI, ModBus RTU, LabView VIs

GET A QUOTE

Add to Quote List View Quote List

Description

Model Overview – All Values

Model	DC Input Power (Max/Derated)	DC Input Voltage (CV Range)	DC Input Current (CC Range)	AC Input (Active PFC)	Type	External Control	Housing	Special Features
ELR 10080-170	5000W / 3000W	0-80V	0-170A	208-480V AC, 3ph	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 3U Rackmount	Energy Recovery up to 94.5%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, SCPI & ModBus RTU, LabView VIs
ELR 10200-70	5000W / 3000W	0-200V	0-70A	208-480V AC, 3ph	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 3U Rackmount	Energy Recovery up to 94.5%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, SCPI & ModBus RTU, LabView VIs
ELR 10360-40	5000W / 3000W	0-360V	0-40A	208-480V AC, 3ph	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 3U Rackmount	Energy Recovery up to 95.5%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, SCPI & ModBus RTU, LabView VIs
ELR 10500-30	5000W / 3000W	0-500V	0-30A	208-480V AC, 3ph	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 3U Rackmount	Energy Recovery up to 95.5%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, SCPI & ModBus RTU, LabView VIs
ELR 10750-20	5000W / 3000W	0-750V	0-20A	208-480V AC, 3ph	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 3U Rackmount	Energy Recovery up to 95.5%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, SCPI & ModBus RTU, LabView VIs
ELR 10080-340	10000W / 6000W	0-80V	0-340A	208-480V AC, 3ph	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 3U Rackmount	Energy Recovery up to 94.5%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, SCPI & ModBus RTU, LabView VIs
ELR 10200-140	10000W / 6000W	0-200V	0-140A	208-480V AC, 3ph	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 3U Rackmount	Energy Recovery up to 94.5%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, SCPI & ModBus RTU, LabView VIs
ELR 10360-80	10000W / 6000W	0-360V	0-80A	208-480V AC, 3ph	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 3U Rackmount	Energy Recovery up to 95.5%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, SCPI & ModBus RTU, LabView VIs
ELR 10500-60	10000W / 6000W	0-500V	0-60A	208-480V AC, 3ph	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 3U Rackmount	Energy Recovery up to 95.5%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, SCPI & ModBus RTU, LabView VIs
ELR 10750-40	10000W / 6000W	0-750V	0-40A	208-480V AC, 3ph	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 3U Rackmount	Energy Recovery up to 95.5%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, SCPI & ModBus RTU, LabView VIs
ELR 11000-30	10000W / 6000W	0-1000V	0-30A	208-480V AC, 3ph	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 3U Rackmount	Energy Recovery up to 95.5%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, SCPI & ModBus RTU, LabView VIs
ELR 11500-20	10000W / 6000W	0-1500V	0-20A	208-480V AC, 3ph	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 3U Rackmount	Energy Recovery up to 95.5%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, SCPI & ModBus RTU, LabView VIs
ELR 10080-510	15000W / 9000W	0-80V	0-510A	208-480V AC, 3ph	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 3U Rackmount	Energy Recovery up to 94.5%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, SCPI & ModBus RTU, LabView VIs
ELR 10200-210	15000W / 9000W	0-200V	0-210A	208-480V AC, 3ph	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 3U Rackmount	Energy Recovery up to 94.5%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, SCPI & ModBus RTU, LabView VIs
ELR 10360-120	15000W / 9000W	0-360V	0-120A	208-480V AC, 3ph	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 3U Rackmount	Energy Recovery up to 95.5%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, SCPI & ModBus RTU, LabView VIs
ELR 10500-90	15000W / 9000W	0-500V	0-90A	208-480V AC, 3ph	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 3U Rackmount	Energy Recovery up to 95.5%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, SCPI & ModBus RTU, LabView VIs
ELR 10750-60	15000W / 9000W	0-750V	0-60A	208-480V AC, 3ph	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 3U Rackmount	Energy Recovery up to 95.5%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, SCPI & ModBus RTU, LabView VIs
ELR 11000-40	15000W / 9000W	0-1000V	0-40A	208-480V AC, 3ph	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 3U Rackmount	Energy Recovery up to 95.5%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, SCPI & ModBus RTU, LabView VIs
ELR 11500-30	15000W / 9000W	0-1500V	0-30A	208-480V AC, 3ph	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 3U Rackmount	Energy Recovery up to 95.5%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, SCPI & ModBus RTU, LabView VIs
ELR 12000-20	15000W / 9000W	0-2000V	0-20A	208-480V AC, 3ph	Programmable Regenerative DC Electronic Load	Analog, USB, Ethernet (Optional: CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT)	19" 3U Rackmount	Energy Recovery up to 95.5%, Master-Slave (up to 64 units), Share Bus, Function Generator, Battery Test, MPPT Tracking, SCPI & ModBus RTU, LabView VIs

30-Second Fit Check

Need an energy-saving DC load for high-power testing? Models cover 0-80V to 0-2000V, with currents up to 510A.
Output power: 5kW, 10kW, or 15kW with regenerative energy recovery up to 95.5% back to the grid.
Four regulation modes: Constant Voltage (CV), Constant Current (CC), Constant Power (CP), Constant Resistance (CR).
Built-in 5" TFT touch panel with two rotary knobs; supports master-slave parallel operation for up to 64 units (960kW).
Comprehensive protection: OVP, OCP, OPP, OT, PF, MSP, SF; Share bus for dynamic current balancing in parallel systems.

What It Is + Why It Matters

Regenerative electronic DC loads in 3U 19" rack format that feed consumed DC energy back to the local grid with up to 95.5% efficiency – drastically reducing cooling costs and energy waste.
An integrated function generator (sine, triangle, square, trapezoid, ramp, DIN 40839, arbitrary, XY table) plus dedicated battery test and MPPT tracking modes for comprehensive component testing.
True master-slave parallel operation with summed actual values and shared setpoints across units, plus a Share bus for dynamic voltage balancing – scalable to 960kW.
Flexible connectivity: built-in analog (0-5/10V), USB, Ethernet, plus optional plug-in modules for CAN, CANopen, RS232, Profibus, ProfiNet, ModBus TCP, EtherCAT.

Note: These are energy-recovering devices that feed power back into the local grid. Consult local utility regulations and consider a grid protection device. Must be installed in a closed 19" rack with proper ventilation.

Key Specs

AC input: 208-480V AC, 3-phase, active PFC, 45-65Hz; derating to 3/6/9kW at 208V input.
DC input voltage: 0-80V up to 0-2000V; Current: 0-20A up to 0-510A.
DC input power: 5kW, 10kW, or 15kW (derating at 208V AC input).
Energy recovery efficiency: up to 95.5%; regulation accuracy: CV ≤0.05%, CC ≤0.1%.
Display: 5" TFT colour touchscreen (800x480), 2 rotary knobs with push function, panel lock.
Interfaces: 15-pin analog (0-5/10V), USB-B, USB-A, Ethernet, plus optional industrial bus modules.
Master-slave bus (RS485 via RJ45) + Share bus (BNC) for up to 64 units parallel operation.
Dimensions (WxHxD): 19" x 3U x 668mm; Weight: approx. 18-33 kg (model dependent).

Integration & Installation

DC input on rear panel with copper blade terminals (M8 or M6 bolts); includes plastic covers for contact protection and strain relief accessories.
AC mains via 5-pole or 4-wire connector (3x L, N, PE); three-phase 208-480V AC with automatic adjustment; derating to 3/6/9kW at 208V.
Master-slave connection via standard CAT5 patch cables; Share bus via BNC coaxial cables (50Ω); supports mixed power classes within the same series.
Optional interface modules are user-installable in the rear slot; ESD precautions apply during module exchange.
Must be installed in a closed 19" rack/cabinet with lockable doors; ensure adequate ventilation and consult grid regulations for energy feedback.

Best for / Not for

Best for: High-power battery discharge testing, solar panel MPP profiling, automotive 400V/800V system validation, power supply burn-in testing, and large-scale industrial test systems requiring energy efficiency and scalable parallel operation.
Not for: AC load applications, series connection of DC inputs (not permitted), operation without proper energy recovery grid compliance, or environments without adequate rack cooling.

Selection Checklist + RFQ

Choose voltage/current model matching your source specifications (80V to 2000V, 20A to 510A).
Confirm total power requirement ≤ 5kW, 10kW, or 15kW; note derating to 3/6/9kW at 208V AC input.
Verify AC supply voltage (208-480V AC three-phase) and plan for proper grid compliance regarding energy recovery.
Select required interfaces: built-in analog/USB/Ethernet plus any optional industrial bus modules (CAN, Profibus, ProfiNet, EtherCAT, etc.).
For master-slave operation, specify total system power and number of units; ensure all units have same voltage rating.
Plan for installation in a closed 19" rack with adequate cooling and lockable doors.
