160W flexiranging programmable desktop DC power supply with 0–200V, 0–2A output, active PFC, and worldwide 90–264VAC input. Features a colour display, two rotary knobs, six pushbuttons, remote sensing, OVP/OCP/OPP/OT protection, and optional galvanically isolated USB/Ethernet/analog interface cards. SCPI, ModBus RTU, and LabView VI supported. Ideal for R&D laboratories, electronics testing, and educational benchtop applications.

Output Current

0-2A

Output Power

0-160W

Output Voltage

0-200V

Characteristic Curve

U/I flexiranging

External Control

USB

Housing

Desktop (table)

Human Interface

Simple manual controls

GET A QUOTE

Add to Quote List View Quote List

Description

30-Second Fit Check

Need a compact benchtop supply for low-power high-voltage testing? Output is 0–200 V, rated 0–2 A.
Rated power: 160 W with flexiranging (U/I) – higher voltage at lower current, higher current at lower voltage.
Wide AC input with active PFC: 90–264 VAC for worldwide use.
Protection set: OVP, OCP, OPP with configurable thresholds, plus OT (overtemperature).
Remote sensing input compensates for voltage drops in load cables automatically.
Colour display with two rotary knobs and six pushbuttons for intuitive manual control.

What It Is + Why It Matters

Compact programmable desktop DC power supply within the 160 W power class, designed for basic lab and test applications.
Flexiranging output stage (auto-ranging) allows a single unit to cover a wide voltage/current range, reducing the need for multiple fixed-range supplies.
Optional galvanically isolated interface cards (USB, USB+Ethernet, USB+Analog) are user-installable for easy remote control upgrade.
Supports SCPI, ModBus RTU, and LabView VI for seamless integration into automated test environments.
Five user profiles enable quick switching between frequently used set value configurations.

Note: Interface cards for remote control are optional and ordered separately. The base unit includes only the manual control panel.

Key Specs

DC Output: 0–200 V, 0–2 A, 160 W (flexiranging).
AC Input: 90–264 VAC with active PFC.
Characteristic curve: U/I flexiranging (auto-ranging) – max. power adjustable.
Protection: OVP (overvoltage), OCP (overcurrent), OPP (overpower), OT (overtemperature).
Remote sensing: standard sense input; device automatically detects when wired and compensates accordingly.
Control: colour display, 2 rotary knobs, 6 pushbuttons; multilingual interface (German, English, Russian, Chinese).
External control: optional plug-in interface cards available – USB, USB+Ethernet, or USB+Analog (galvanically isolated).
Protocols supported: SCPI, ModBus RTU; LabView VI compatible.
Software included: "EA Power Control" for Windows (sequencing, CSV table control, multi-unit control with optional licence).
Housing: desktop enclosure with carrying handle and tilt stand.
User profiles: 5 storable profiles for set values, protection limits, and configuration.

Integration & Installation

Compact desktop format; carrying handle doubles as tilt stand for ergonomic bench angle.
Front panel: DC output terminals, remote sense input, colour display, two rotary knobs, six pushbuttons.
Rear panel: AC inlet, slot for optional interface card.
Interface cards (optional): USB (33100232), USB+Ethernet (33100233), USB+Analog (33100234) – user-installable on location.
Software: Windows-compatible "EA Power Control" included; optional "Multi Control" licence for up to 20 units simultaneously.

Best for / Not for

Best for: R&D benchtop testing, electronics development, university education, and low-power applications requiring up to 200 V or precise current control up to 2 A.
Not for: applications needing output voltage above 200 V, current beyond 2 A, or sustained power exceeding 160 W. Remote control requires optional interface card.

Selection Checklist + RFQ

Confirm required output range fits 0–200 V, 0–2 A, and max. 160 W.
Verify AC mains: 90–264 VAC single-phase.
If remote control is needed, select and order the appropriate interface card: USB (33100232), USB+Ethernet (33100233), or USB+Analog (33100234).
For sequencing or automated testing, ensure "EA Power Control" software meets your workflow requirements.
Plan bench space and cooling; the carrying handle allows angled positioning for improved display readability.
