EA-EL 9200-36 DT 1000W

1000W programmable 3U DC electronic load with 0–200V, 0–36A autoranging input, CV/CC/CP/CR modes, and 4.3″ TFT touch panel. Built‑in function generator (sine, triangle, rectangle, arbitrary, ramp), battery test, and MPPT tracking. Remote control via galvanically isolated analog (0–5V/10V), USB, and Ethernet (ModBus/SCPI). Compact 276×103×355mm desktop housing with optional 19″ rack‑mount kit. Ideal for medium‑voltage R&D, ATE, and solar simulation.

Output Current
0-36A
Output Power
1000W
Output Voltage
0-200V
Type
3U
Characteristic Curve
U/I/P autoranging
External Control
Analogue 0-5V/0-10V, USB, LAN, Modbus
Housing
19" rack
Human Interface
Touch panel & Menu
Special Feature
Function Generator, Resistance
  • EA-EL 9200-36 DT 1000W

Description

30-Second Fit Check

  • Need a medium‑voltage DC load for power supply testing? Input is 0–200 V, rated 0–36 A.
  • Rated power: 1000 W peak, 900 W steady (autoranging U/I/P).
  • Operates in CV, CC, CP, CR modes with automatic crossover.
  • AC supply: 90–264 VAC, 45–65 Hz; consumption max. 40 W, fuse T 2 A.
  • Protection: configurable OVP (0–206 V), OCP (0–39.6 A), OPP (0–1100 W), plus OT and PF.
  • Dimensions: 276 × 103 × 355 mm; total depth 451 mm; weight approx. 7.5 kg; optional 2U rack‑mount kit.

What It Is + Why It Matters

  • High‑precision programmable DC electronic load for R&D, production testing, and medium‑voltage applications.
  • Autoranging (U/I/P) provides flexible voltage/current combinations—one unit handles diverse test conditions.
  • Integrated function generator (sine, triangle, rectangle, trapezoid, DIN 40839, arbitrary, ramp) and resistance simulation eliminate external waveform sources.
  • Battery discharge test (static/dynamic) with Ah/Wh counters and MPPT tracking (4 modes) for solar panel characterisation.
  • Galvanically isolated analog 0‑5/10 V interface plus USB and Ethernet (ModBus RTU/SCPI) ready for ATE integration.
Note: The peak power of 1000 W is available for a limited time; steady‑state power is 900 W at 25 °C. The internal temperature‑dependent derating reduces power gradually.

Key Specs

  • DC Input: 0–200 V max., max. allowed 220 V; min. voltage for full current ≈ 2 V.
  • Current: 0–36 A max., adjustable 0–36.72 A; accuracy ≤0.2% IMax.
  • Power: 1000 W peak, 900 W steady; accuracy <0.5% PSteady.
  • Resistance: 0.5–173.4 Ω; accuracy ≤1% RMax + 0.3% IMax.
  • Voltage accuracy: ≤0.1% UMax; stability at ΔI <0.05% UMax; remote sensing compensation max. 5% UMax.
  • Rise/fall time: <40 µs / <42 µs (10–90% INom).
  • Display: 4.3″ colour TFT touch panel (capacitive, gorilla glass), 480×272 pt.
  • Interfaces: USB‑B (rear, CDC), USB‑A (front, data/logging), Ethernet (10/100 MBit, SCPI/ModBus), 15‑pole Sub‑D analog (0‑5/10 V, galvanically isolated, 500 Hz sample rate).
  • Function generator: sine, triangle, rectangle, trapezoid, DIN 40839, arbitrary (99 sequences), ramp; plus battery test and MPPT.
  • Standards: EN 60950:2006 + amendments; EN 61000‑6‑3:2011, EN 61000‑6‑1:2007.

Integration & Installation

  • Desktop enclosure with carrying handle/tilt stand; can be installed in a 19″ rack using the optional 2U mounting frame (order nr. 10 400 111).
  • Front panel: DC input terminals (clamp & plug; 4 mm system plugs for max. 32 A, spade lugs for ≤36 A), USB‑A, remote sense, control panel.
  • Rear panel: AC inlet with fuse (T 2 A), USB‑B, Ethernet, 15‑pole Sub‑D analog interface.
  • Cooling: temperature‑controlled fans; leave ≥30 cm clearance behind the unit.
  • DC wiring: for 36 A, recommended cable cross section ≥10 mm² (AWG8) up to 5 m.

Best for / Not for

  • Best for: medium‑voltage power supply testing, DC‑DC converter validation, battery discharge profiling, solar panel MPPT characterisation, production ATE, and R&D laboratories.
  • Not for: sources exceeding 200 V / 36 A / 1000 W; series connection of loads not permitted.

Selection Checklist + RFQ

  • Confirm source voltage ≤ 200 V, current ≤ 36 A, sustained power ≤ 900 W (peak ≤1000 W).
  • Select regulation mode (CV/CC/CP/CR) and set OVP/OCP/OPP thresholds for source protection.
  • Choose remote interface: USB, Ethernet (ModBus/SCPI), or galvanically isolated analog (0‑5/10 V).
  • If rack mounting is required, order the optional 2U mounting frame (10 400 111).
  • For battery or MPPT testing, verify that the built‑in function parameters match your test profile.
  • Ensure adequate ventilation; the temperature‑dependent derating allows 1000 W peak before settling to 900 W steady.
